Ubiquiti LTU Rocket Outdoor 5GHz PtMP LTU BaseStation Radio
fullscreen

Ubiquiti LTU Rocket Outdoor 5GHz PtMP LTU BaseStation Radio

Rated 0/5   0 reviews | 0 Questions
Ubiquiti logo Ubiquiti
  • Point to Multipoint
  • Advanced Filtering
  • 600+ Mbps Performance
Link to videos

The Ubiquiti LTU Rocket is an outdoor Point to Multipoint 5GHz LTU BaseStation Radio access point with up to 600+ Mbps throughput & advanced filtering (Read more)

Loading
Discontinued
Product Code18020
ModelLTU-ROCKET
SPECIAL ORDER / NON-RETURNABLE ITEM
More Information
RELATED PRODUCTS

PRODUCT DETAILS

The Ubiquiti LTU Rocket is an outdoor, Point to Multipoint 5GHz LTU BaseStation Radio access point with advanced filtering performance and up to 600+ Mbps throughput. Channel width flexibility (10/20/30/40/50 MHz) allows independent TX and RX channel frequency configurations anywhere within the radio band to avoid local interference, and a custom co-processor is included for future performance and feature upgrades.

The LTU-ROCKET comes complete with a 24V, 1A Gigabit PoE adapter, an external GPS antenna, an IP67 upgrade kit, and all of the required mounts and brackets.


Interface


ltu-rocketinterface1.png?h=550



Features:

  • 600+ Mbps PtMP performance (1+ Gbps with future firmware upgrade).
  • Up to sixty-four (64) client connections per AP.
  • 2+ Million pps.
  • Proprietary RF filtering.
  • Integrated GPS for improved synchronisation.
  • 10/20/30/40/50/100 MHz Channel Width Flexibility.
  • By default, the Auto Output Power option allows the LTU Rocket to set the output power (EIRP) to the appropriate level.
  • Can use different frequencies for TX and RX to avoid interference.
YOU MIGHT ALSO NEED
Loading





Loading





Loading





Loading





Loading





Loading





SPECIFICATIONS
Mechanical
Dimensions
244 x 82 x 48 mm (9.61 x 3.23 x 1.89")
Weight
486 g (1.03 lb)
Enclosure materials
Diecast aluminum, polycarbonate
Mounting
Integrated pole mount (Kit included)
GPS pole mount (Kit included)
Rocket mount compatible
Weatherproofing
IP67
Hardware
Networking interface
(2) GbE RJ45 ports
Power method
Passive PoE 4-Pair (Pins 1, 2; 4, 5+ and Pins 3, 6; 7, 8-)
Power supply
24V, 1A Gigabit PoE adapter (Included)
Supported voltage range
18–54V DC
Max. power consumption
15W
RF connections
(2) RP-SMA weatherproof (CH0, CH1)
(1) SMA weatherproof (GPS)
GPS
Yes
GPS antenna
External magnetic base
Button
Factory reset
Operating temperature
-40 to 55° C (-40 to 131° F)
Operating humidity
5 to 95% noncondensing
Certifications
FCC, IC, CE
Software
Mode
PtMP BaseStation radio
Services
SNMP, SSH, dynamic DNS, webserver, remote log, ping watchdog
Utilities
airView®, speed test, alignment, discovery, ping, traceroute, cable test, constellation
Auto distance adjustment
Yes
Auto power adjustment
Yes
Security
Yes
Statical reporting
Yes
Management interface
Bluetooth management for easy setup over UISP Mobile app WEB UI
Minimum software requirements
Any modern web browser
iOS™ or Android™ based smartphone
System
Maximum throughput
900+ Mbps*
*FW version 2.3.0 and later
Packets per second
2+ million
Max. range
100+ km*
* Throughput and range values may vary depending on the environmental conditions
Supported clients count
100+
Encryption
WPA2-PSK (AES)
Uplink/Downlink ratio
25/75, 33/67, 50/50
RF
Operating frequency*



US/CA
U-NII-1
5150 - 5250 MHz
U-NII-2A
5250 - 5350 MHz
U-NII-2C
5470 - 5725 MHz
U-NII-3
5725 - 5850 MHz


Worldwide
4800 - 6200 MHz
*Depends on regulatory region
Max. conducted TX power
29 dBm
Channel bandwidth
10/20/30/40/50/60/80/100 MHz* selectable
Programmable uplink and downlink duty cycles
*FWversion2.3.0andlater.
Management radio
2400 - 2483.5 MHz
