HiLook IPC-B159H/GREY 5MP IP Colorvu PoE Bullet Camera 2.8mm
The HiLook IPC-B159H/GREY is a 5MP IP bullet camera with a 2.8mm fixed lens, and 24/7 full colour images thanks to Hikvision's ColorVu technology. (Read more)
PRODUCT DETAILS
The HiLook IPC-B159H/GREY is a 5MP IP bullet camera with a 2.8mm fixed lens, and features 24/7 full colour images thanks to Hikvision's ColorVu technology. H.265+ compression greatly reduces transmission bandwidth and storage capacity required and PoE (Power over Ethernet) only requires a single cable for both power and the picture, which makes installation quick and efficient.
ColorVu Lite
Full colour night-time imaging is now available on HiLook cameras with ColorVu Lite technology.
Colorvu technology is designed to deliver clear colour images in scenes with almost no light without relying on infrared. Colorvu works by combining large image sensors with advanced image processing which in independent tests has proven to deliver the best images in scenes with very little light.
Colorvu Lite cameras feature a built-in white light that can provide illumination in complete darkness which allows the camera to deliver full colour images 24 hours a day regardless of the lighting condition.
Having colour images helps with subject identification, number plates capture and provides accurate context which is lost on conventional cameras.
H.265+ Compression Technology
HiLook lifts video surveillance to an unprecedented level with its H.265+ codec. In Full HD mode, H.265+ uses less than 20% of the bandwidth of H.264, allowing for live streams of unrivalled quality.
H.265+ also greatly outperforms all its predecessors in terms of storage. Regardless of environment or application, H.265+ reduces the required storage space by more than 80%. In short, H.265+ allows you to kill two birds with one stone: you can now record images at amazingly high resolutions and minimize the required storage capacity. This makes H.265+ the ideal solution for 24-hour surveillance
DORI - Recommended operational range of the camera
DORI is a standardized system that provides a clear framework for evaluating the effectiveness of CCTV cameras. It is based on the European standard EN 62676-4, which defines specific criteria for detecting, observing, recognizing, and identifying objects or individuals within a camera's field of view. For more information on understanding the DORI metrics, please read our blog article here.
The DORI specifications for this camera are:
Detection: 64m
Observation: 25m
Recognition: 2.8m
Identification: 6.4m
Features:
- High quality imaging with 2 MP resolution
- Excellent low-light performance
- Efficient H.265+ compression technology
- Water and dust resistant (IP67)
- 24/7 colourful imaging
- PoE (Power over Ethernet)
Camera | |
Image Sensor | 1/3" Progressive Scan CMOS |
Max. Resolution | 2560 × 1440 |
Min. Illumination | Colour: 0.001 Lux @ (F1.0, AGC ON), B/W: 0 Lux with white light |
Shutter Speed | 1/3 s to 1/100, 000 s |
Day & Night | 24/7 Colour imaging |
Angle Adjustment | Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
Lens | |
Lens Type | Fixed focal lens, 2.8 mm |
Focal Length & FOV | 2.8 mm, horizontal FOV 96.5°, vertical FOV 50.8°, diagonal FOV
113.9° |
Lens Mount | M12 |
Iris Type | Fixed |
Aperture | F1.0 |
DORI | |
DORI | 2.8 mm, D: 64.0 m, O: 25.4 m, R: 12.8 m, I: 6.4 m |
Illuminator | |
Supplement Light Type | White light |
Supplement Light Range | Up to 30 m |
Smart Supplement Light | Yes |
Video | |
Main Stream | 50 Hz: 20 fps (2560 × 1440) 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 20 fps (2560 × 1440), 30 fps (1920 × 1080, 1280 × 720) |
Sub-Stream | 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360) |
Video Compression | Main stream: H.265+/H.264+/H.265/H.264 Sub-stream: H.265/H.264/MJPEG |
Video Bit Rate | 32 Kbps to 8 Mbps |
H.264 Type | Baseline Profile/Main Profile/High Profile |
H.265 Type | Main Profile |
Region of Interest (ROI) | 1 fixed region for main stream |
Network | |
Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS |
Simultaneous Live View | Up to 6 channels |
API | Open Network Video Interface, ISAPI |
User/Host | Up to 32 users. 3 levels: administrator, operator and user |
Client | iVMS-4200, Hik-Connect |
Web Browser | Plug-in required live view: IE 10+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+ Local service: Chrome 57.0+, Firefox 52.0+ |
Image | |
Image Settings | Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser. |
Day/Night Switch | Day, Night, Auto, Schedule |
Wide Dynamic Range (WDR) | 120 dB |
Image Enhancement | BLC, 3D DNR |
Interface | |
Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
Event | |
Basic Event | Motion detection, video tampering alarm, exception |
Linkage | Upload to FTP, notify surveillance center, send email, trigger capture |
General | |
Power | 12 VDC ± 25%, 0.4 A, max. 5 W, Ø5.5 mm coxial power plug PoE: 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W |
Camera Material | Aluminum alloy body |
Camera Dimension | Ø76.6 mm × 164.4 mm (Ø3" × 6.5") |
Package Dimension | 234 mm × 120 mm × 117 mm (9.2" × 4.7" × 4.6") |
Camera Weight | Approx. 425 g (0.9 lb.) |
With Package Weight | Approx. 633 g (1.4 lb.) |
Storage Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing) |
Startup and Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing) |
Web Client Language | English, Ukrainian |
General Function | Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter |
Approval | |
EMC | FCC SDoC: 47 CFR Part 15, Subpart B; CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 50130-4: 2011 +A1: 2014 RCM: AS/NZS CISPR 32: 2015; KC: KN 32: 2015, KN 35: 2015 |
Safety | CB: IEC 62368-1: 2014+A11; CE-LVD: EN 62368-1: 2014/A11: 2017; BIS: IS 13252 (Part 1): 2010/ IEC 60950-1: 2005 |
Environment | CE-RoHS: 2011/65/EU; WEEE: 2012/19/EU; Reach: Regulation (EC) No 1907/2006 |
Protection | IP67: IEC 60529-2013 |
Videos |
---|
Files |
---|
HiLook IPC-B159H/GREY Datasheet |
Links* |
---|
HiLook by Hikvision website |
HiLook by Hikvision support site |
