Ajax Jeweller EN54 I/O Module (2X2)
Ajax
- 2 Input & 2 Output
- EN 54-18 Certified
- 2 year guarantee
The Ajax EN54 I/O Module (2×2) is a professional-grade, black input/output interface module designed for use with Ajax EN54-certified fire systems. (Read more)
PRODUCT DETAILS
The Ajax EN54 I/O Module (2×2) is a professional-grade input/output interface module designed for use with Ajax EN54-certified fire systems. It provides reliable integration between the Ajax Fire Hub Jeweller and third-party fire protection or building management devices, enabling advanced automation and system interoperability.
With two inputs and two relay outputs, the module allows connection of devices such as fire alarms, sirens, ventilation systems, gas shut-off valves, or other signalling units. It supports EN 54-18 compliance, ensuring it meets European fire safety standards for control and indication equipment.
Pre-installed batteries provide up to 5 years of autonomous operation. Real-time battery status is always visible in Ajax apps, so there is no need for unnecessary maintenance visits. Service companies also receive early low battery notifications for timely replacements. When it's time to change the batteries, the process is fast and straightforward: an installer simply removes the module's front lid.
Features:
- 2 input and 2 output channels – ideal for connecting and controlling external fire system components
- EN 54-18 certified – meets European fire alarm interface standards
- Flexible integration – enables connection with third-party equipment such as HVAC controls, door releases, and gas valves
- Secure wireless communication via Ajax Jeweller technology with up to 1,700 m range (line-of-sight)
- Real-time monitoring – inputs detect the state of connected devices and relay changes instantly to the Ajax control panel
- Tamper protection – alerts the system if the module housing is opened or removed
- Compact design – easy to install inside junction boxes or control enclosures
- Black enclosure finish (124591.280.BL1) – blends neatly with professional control cabinet layouts
| Communication |
|
| Jeweller communication technology |
Proprietary wireless communication
technology to transmit commands, alarms, and events. Key features: Two-way communication. Advanced sabotage protection. Block encryption featuring a dynamic key. Instant notifications. Remote control and configuration in Ajax apps. |
| Frequency bands |
866.0 – 866.5 MHz 868.0 – 868.6 MHz 868.7 – 869.2 MHz 905.0 – 926.5 MHz 915.85 – 926.5 MHz 921.0 – 922.0 MHz |
| Maximum effective radiated power
(ERP) |
up to 20 mW Automatic power control to reduce power consumption and radio interference. |
| Radio signal modulation |
GFSK |
| Radio communication range |
up to 1,700 m Between the device and a control and indicating equipment (CIE) or a range extender in an open space. |
| Encrypted communication |
All stored and transmitted data is protected
by block encryption featuring a dynamic key. |
| Frequency hopping |
To prevent radio interference and
jamming. |
| Inputs |
|
| Number of input lines for third-party
devices |
2 |
| Input terminals |
Input 1, Input 2 — inputs for connecting third-party wired
devices. Shield — common input for connecting shields of the cables that connect third-party wired devices. |
| Type of connection |
NO, NC, EOL, 2EOL, 3EOL |
| EOL resistance |
0.47 kΩ, 1.2 kΩ, 2.7 kΩ, and 6.2 kΩ resistors Four resistors for each input are included in the complete set. |
| Length of wired connection to third-party devices |
up to 100 m When 2×1.5 mm2 (16 AWG) fire-resistant cable is used. |
| Cross-sectional area of the cable |
0.4–2.5 mm² (21–13 AWG) |
| Outputs |
|
| Number of output lines for third-party devices |
2 |
| Output terminals |
Output 1, Output 2 — relay outputs for connecting third-party
wired devices. |
| AC operating range |
10—250 V~, 5 mA to 10 A (resistive load) |
| DC operating range |
10—30 V⎓, 5 mA to 5 A (resistive load) |
| Cross-sectional area of the cable |
0.4–2.5 mm² (21–13 AWG) |
| Key features |
|
| Event types |
An Ajax app specifies event types for wired device inputs. The
selected type determines the text of alarm notifications and events
of the connected device, as well as event codes transmitted to the
CMS. A PRO or a user with admin rights can configure the event type
in an Ajax app. |
| Fail-safe mode |
If the module is offline, discharged, or has hardware problems,
it activates the connected devices automatically. |
| Installation recommendations |
The device is designed for indoor use only. |
| Sabotage
protection |
|
| Tamper alarm |
Notifications of attempts to detach the module from the surface
or open the front lid. |
| Protection against spoofing |
device authentication |
| Connection loss detection |
after 36 s Detection time depends on Jeweller settings. |
| Input monitoring |
detection of wired connection loss, short circuits, and
malfunctions when the EOL, 2EOL, or 3EOL connection is used Depends on the connection type. |
| Power supply |
|
| Battery |
2 × CR123A Pre-installed. |
| Calculated battery life |
up to 5 years |
| Casing |
|
| Dimensions |
116 × 180 × 62 mm |
| Weight |
547 g |
| Operating temperature range |
from 0 °C to +50 °C |
| Operating humidity |
up to 80% |
| Protection class |
IP21C |
| Flammability rating |
UL 94 V-0 |
| Complete set |
EN54 I/O Module (2X2) Jeweller 2 × CR123A battery (pre-installed) Installation kit 2 × set of 4 EOL resistors Quick start guide |
| AJA0369 | EN54 I/O Module (2X2) White | In stock | |
| AJA0368 | EN54 I/O Module (2X2) Black | In stock |
