Ajax CombiProtect U Jeweller PIR & Break Glass
Ajax
- PIR & Break Glass Detector
- Pet Immune
- Controlled Though App
The Ajax CombiProtect U is a combined pet immune wireless motion and glass break detector that works with the Ajax Jeweller wireless alarm systems. (Read more)
PRODUCT DETAILS
The Ajax CombiProtect U Jeweller is a reliable 2-in-1 wireless motion and glass break detector designed to provide fast, accurate intrusion detection while minimising false alarms. Combining a PIR motion sensor with an advanced acoustic glass break sensor, it delivers comprehensive room protection from a single compact device.
Powered by Ajax’s new U-Jeweller wireless protocol, the CombiProtect U offers extended communication range, enhanced resistance to interference, and long-lasting energy efficiency—ideal for both residential and commercial installations. It accurately detects human movement up to 12 metres, while recognising the distinct sound patterns of breaking glass up to 9 metres, ensuring complete perimeter protection.
Features:
- Dual detection technology – PIR motion + acoustic glass break sensor
- U-Jeweller wireless communication – long-range, secure transmission (up to 1,700 m line-of-sight)
- 12 m motion detection with a wide 88.5° field of view
- Glass break detection up to 9 m – monitors multiple windows in a room
- Pet immunity up to 20 kg – avoids false alarms caused by small animals
- Advanced sound analysis – detects both impact and shattering frequencies
- Automatic temperature compensation for consistent performance
- Tamper protection – alerts if the device is opened or removed
- Up to 5 years battery life for low-maintenance operation
- Easy installation with SmartBracket and quick QR-code pairing
- Compatible with Ajax hubs and range extenders using the U-Jeweller protocol
| Communication |
|
| Jeweller communication technology |
Proprietary wireless communication
technology to transmit commands, alarms, and events. Key features: Two-way communication. Advanced sabotage protection. Block encryption featuring a dynamic key. Instant notifications. Remote control and configuration in Ajax apps. |
| Frequency bands |
868.0–868.6 MHz |
| Maximum effective radiated power
(ERP) |
up to 20 mW Automatic power control to reduce power consumption and radio interference. |
| Radio signal modulation |
GFSK |
| Radio communication range |
up to 1,200 m Between the device and a hub (or a range extender) in an open space. |
| Encrypted communication |
All stored and transmitted data is protected
by block encryption featuring a dynamic key. |
| Frequency hopping |
To prevent radio interference and
jamming |
| Motion detection |
|
| Sensitive element |
1 × PIR sensor |
| Motion detection distance |
up to 12 m When installed at a height of 2.4 m |
| Motion detection angle |
horizontal: 88.5° |
| Motion detection speed |
from 0.3 to 2.0 m/s The direction of the detector lens should be perpendicular to an alleged intrusion path into the facility. |
| Sensitivity |
3 levels Adjusted by a PRO or a user with admin rights in Ajax apps. |
| Pet immunity |
weight: up to 20 kg height: up to 50 cm |
| False alarm prevention |
SmartDetect Software algorithm |
| Temperature compensation |
Effective motion detection at temperatures from −10 °C to +40
°C |
| Recommendations |
It is recommended to install the detector at a height of 2.4
m. The device is designed for indoor use only. |
| Glass break
detection |
|
| Sensitive elements |
electret microphone |
| Glass break detection distance |
from 0.3 up to 9 m |
| Glass break detection angles |
horizontal: 180° vertical: N/A |
| Sensitivity |
3 levels Adjusted by PRO or user with admin rights in the Ajax app. |
| False alarm prevention |
DualTone Two-factor glass break verification software algorithm: by low and high frequencies. |
| Glass break
characteristics |
|
| Min size of the glass |
400 × 400 mm Detection distance up to 9 m for all glass types when the High sensitivity level is selected. |
| Type of glass and its thickness |
standard pane — 4 mm insulated glass — 4 mm |
| Sabotage
protection |
|
| Tamper alarm |
Notifications on attempts to detach the detector from the
surface or remove it from the mounting panel. |
| Holding screw |
to secure the detector on SmartBracket |
| Protection against spoofing |
device authentication |
| Communication loss detection |
after 36 s Detection time depends on the Jeweller/Fibra settings. |
| Power supply |
|
| Battery |
1 × CR123A Pre-installed |
| Type |
type C |
| Calculated battery life |
up to 5 years |
| Operating voltage range |
2.1−3.3 V⎓ |
| Nominal operating voltage |
3 V⎓ |
| Quiescent current consumption at nominal voltage |
34 µA |
| Maximum current consumption at nominal voltage |
58 mA |
| Full battery capacity |
1,600 mAh |
| Low battery voltage |
2.5 V⎓ |
| Low battery recovery voltage |
2.7 V⎓ |
| End-of-life battery voltage |
2.7 V⎓ |
| End-of-life battery capacity |
300 mAh |
| Enclosure |
|
| Dimensions |
110 × 65 × 50 mm |
| Weight |
92 g |
| Operating temperature range |
from −10 °C to +40 °C |
| Operating humidity |
up to 75% |
| Protection class |
IP50 |
| Complete set |
CombiProtect U Jeweller SmartBracket mounting panel with holding screw CR123A battery (pre-installed) Installation kit Quick start guide |
| AJA0400 | CombiProtect U Jeweller Black | In stock | |
| AJA0399 | CombiProtect U Jeweller White | In stock |
