Ajax Superior StreetSiren Plus Jeweller Outdoor Sounder
Ajax
- LED Light Up Frame
- 113 dB Adjustable Siren
- Built-in Accelerometer
The Ajax Superior StreetSiren Plus Jeweller is an outdoor wireless siren with a powerful adjustable alarm output up to 113 dB and LED strobe frame. (Read more)
PRODUCT DETAILS
The Ajax Superior StreetSiren Plus Jeweller is a high-performance outdoor wireless siren designed for professional security installations that demand maximum reliability, visibility, and alarm impact. As part of the Ajax Superior series, it features enhanced durability, advanced tamper protection, and upgraded performance ideal for commercial, industrial, and high-risk environments.
Producing a powerful adjustable alarm output up to 113 dB, the Superior StreetSiren Plus ensures that intrusions or emergency events are immediately noticed across large outdoor areas. A full-perimeter LED strobe frame provides bright visual indication, while an integrated accelerometer detects attempts to move, remove, or tamper with the device.
Using Ajax’s secure Jeweller wireless protocol, the siren maintains stable two-way communication with the hub at distances up to 1,700 metres (line-of-sight), guaranteeing rapid alarm delivery and low power consumption for long-term operation.
Features:
- 113 dB adjustable siren output – loud and clear alarm signalling for outdoor environments
- LED perimeter lighting – bright strobe indication for alarms and system statuses
- Superior-series durability – upgraded materials and design for high-risk and commercial sites
- Jeweller wireless communication – secure, long-range performance up to 1,700 m
- Built-in accelerometer – instant alerts for tampering, vibration, or removal attempts
- Extended battery life – efficient energy use for years of dependable operation
- IP54 weather resistance – engineered to withstand rain, dust, wind, and changing temperatures
- Customisable alarm duration & volume – adjustable directly through the Ajax app
- Tamper protection – detects device opening or detachment
- Easy installation – uses SmartBracket mounting for fast, clean fitting
| Communication |
|
| Jeweller communication technology |
Proprietary wireless communication
technology to transmit commands, alarms, and events. Key features: Two-way communication. Advanced anti-sabotage. Block encryption featuring a dynamic key. Instant notifications. Remote control and configuration in Ajax apps. |
| Frequency bands |
866.0–866.5 MHz 868.0–868.6 MHz 868.7–869.2 MHz 905.0–926.5 MHz 915.85–926.5 MHz 921.0–922.0 MHz |
| Maximum effective radiated power
(ERP) |
up to 25 mW Automatic power control to reduce power consumption and noise interference. |
| Radio signal modulation |
GFSK |
| Radio communication range |
up to 1,500 m Between the siren and a hub (or a range extender) in an open space. |
| Encrypted communication |
All stored and transmitted data are
protected by block encryption featuring a dynamic key. |
| Frequency hopping |
To prevent radio interference and
jamming. |
| Key features |
|
| Alarm type |
acoustic and light A speaker and LED frame. |
| Type of warning device |
type X External, self-powered, remote power source with EN 50131-6 compliant power supply. |
| Alarm volume |
from 85 to 107 dB at a distance of 1 m Adjusted by a PRO or user with admin rights in the Ajax app. |
| Alarm duration |
from 3 s to 3 min Adjusted by a PRO or user with admin rights in the Ajax app. |
| Alarm sound |
2 types NFA2P-compliant and Regular. |
| LED indication |
2 types If the siren has an external power supply, the user can choose between the Corner backlight and Full-frame backlight features. If the siren is powered by a battery, only the Corner backlight feature is available. |
| Alarm LED indication in NFA2P-compliant mode |
flashlight colour — red flashlight frequency — 1 flash per second |
| Siren sound frequency |
1,400−1,600 Hz in NFA2P-compliant mode 1,400−1,600 Hz in Regular mode |
| Device self-test |
Allows you to check whether the battery is sufficiently charged
for normal operation. |
| Events indication |
Alarms. Delays when entering/leaving. Security mode. Security mode changing. After-alarm indication. |
| Chime |
The siren makes a special sound to notify that the opening
detectors are triggered when the facility is disarmed. |
| Recommendations |
The siren is designed for indoor and outdoor use. Recommended installation height is 2.5 m or higher. |
| Sabotage
protection |
|
| Tamper alarm |
Notifications on attempts to open the siren’s enclosure, detach
the siren from the surface, or remove the siren from the mounting
panel. |
| Protection against spoofing |
device authentication |
| Jamming detection |
The siren detects jamming and alarms about it. |
| Communication loss detection |
after 36 s Detection time depends on the Jeweller or Jeweller/Fibra settings. |
| Power supply |
|
| Batteries |
8 × CR123A 3 V⎓ lithium battery Pre-installed. |
| Type |
Type C |
| Calculated battery life |
up to 10 years |
| Siren’s operating voltage range |
3.65−6.2 V⎓ |
| Siren’s nominal operating voltage |
3 V⎓ in standby mode 6 V⎓ when the siren sounds |
| Quiescent siren’s current consumption |
75.6 µA |
| Peak siren’s current consumption at nominal voltage |
690 mА When the siren sounds at the Very loud volume level. |
| Average siren’s current consumption at nominal
voltage |
126 mA When the siren sounds at the default volume level. Regardless of the arming mode. |
| Full capacity |
12,800 mAh |
| Low battery voltage |
4.65 V⎓ |
| End-of-life battery voltage |
3.65 V⎓ |
| Manufacturer |
Huiderui |
| Electric shock protection class |
Class III |
| Optional power
supply |
|
| Remote power supply’s operating voltage |
9.6−14.4 V⎓ |
| Remote power supply’s nominal voltage |
12 V⎓ |
| Quiescent siren’s current consumption at nominal
voltage |
8 mA |
| Average siren’s current consumption at nominal
voltage |
80 mA |
| Peak siren’s current consumption at nominal voltage |
420 mA |
| Enclosure |
|
| Dimensions |
210 × 210 × 71 mm |
| Weight of the white device |
1,146 g |
| Weight of the black device |
1,124 g |
| Operating temperature range |
from −25 °C to +60 °C |
| Operating humidity |
up to 95% with no condensation |
| Protection class |
IP54, IK08 |
| Complete set |
Superior StreetSiren Plus Jeweller SmartBracket mounting panel Installation kit Quick start guide |
| AJA0317 | Ajax Superior StreetSiren Plus Jeweller White | In stock | |
| AJA0316 | Ajax Superior StreetSiren Plus Jeweller Black | In stock |
