Hikvision DS-D5024F2-BV2S 24-Inch 100hz VA Monitor, HDMI, VGA, VESA
Hikvision
- Built-in Speakers
- Ultra-Thin Border
- 2 year guarantee
The Hikvision DS-D5024F2-BV2S is a 24" monitor with 1080p HD resolution and features VGA & HDMI interfaces, built-in speakers & VESA 100 x 100 mount. (Read more)
PRODUCT DETAILS
The Hikvision DS-D5027F3-2P2S is a 27" monitor with an 8 bit LVDS FHD1080p resolution display and supports multiple interfaces including HMDI and VGA. It features an E-LED backlit screen and the 1080p display provides excellent colour rendition and enhanced resolution. Its ultra-thin bezels showcase the display and offer a sleek modern look.
The DS-D5027F3-2P2S boasts a 178° viewing angle and built-in 2W stereo speakers, and can be desk mounted, or wall mounted using 100 x 100 VESA.
Hikvision's incredibly durable monitors are specially designed for security and control environments. Featuring industry grade panels and sharp, brilliant image clarity, the DS-D5027F3-2P2S is the ideal monitor for every viewing need - 24 hours a day, 7 days a week.
Features:
- VA technology , 178° ultra-wide view screen.
- 8 bit LVDS FHD (1920 × 1080) display.
- 100 Hz refresh rate, more fluid and life-like video.
- Ultra-thin device body with ultra-thin border for 3 sides.
- 3D noise reduction.
- Low blue light design for eye care.
- Dual interface of HDMI and VGA.
- Support VESA wall mount.
- Built-in speaker for audio input.
| Display | |
| Screen Size | 23.8 inch, 60.45 cm |
| Active Display Area | 527.04 (H) mm × 296.46 (V) mm, 15.62 dm² |
| Resolution | 1920 × 1080 |
| Backlight | E-LED |
| Pixel Pitch | 0.2745 (H) mm × 0.2745 (V) mm |
| Brightness | 250 cd/m² |
| Viewing Angle | 178° (H) / 178° (V) |
| Color Depth | 8 bit ,16.7 M |
| Contrast Ratio | 4000 : 1 |
| Response Time | 7 ms |
| Refresh Rate | Typ. 60 Hz , Max. 100Hz |
| Haze | Haze 25% |
| Reliability | 7 × 24 H |
| Color Gamut | 72% NTSC |
| Interface | |
| Video & Audio Input | HDMI 1.4 × 1, VGA × 1, Audio IN × 1 |
| Video & Audio Output | Speaker × 2 ( 4Ω 2W) |
| Data Transmission Interface | None |
| Control Interface | None |
| Power | |
| Power Supply | DC 12V, 2.0A |
| Power Consumption | ≤ 24 W |
| Standby Consumption | ≤ 0.5 W |
| Working Environment | |
| Working Temperature | 0℃ to 40 ℃ (32 ℉ to 104 ℉) |
| Working Humidity | 20% to 90% RH (Non-Condensing) |
| Storage Temperature | -20 ℃ to 60 ℃ (-4 ℉ to 140 ℉) |
| Storage Humidity | 10% to 90% RH (Non-Condensing) |
| General | |
| Casing Material | Plastic |
| VESA | 75 mm × 75 mm (4 - M4 × 6 mm) |
| Bezel Width | 2.0 mm (top/left/right), 23.55 mm (bottom) |
| Product Dimensions (W × H × D) | With base: 539.7 (W) mm × 399.9 (H) mm × 164.72(D) mm 21.25 (W) inch × 15.74 (H) inch × 6.49 (D) inch Without base: 539.7 (W) mm × 327.33 (H) mm × 43.5 (D) mm 21.25 (W) inch × 12.89 (H) inch × 1.71 (D) inch |
| Package Dimensions (W × H × D) | 611 (W) mm × 405 (H) mm × 118 (D) mm (24.06(W) × 15.94(H) × 4.65 (D) ) inch |
| Standby Time | 600s |
| Net Weight | 2.85 ± 0.5 kg |
| Gross Weight | 3.85± 0.5 kg |
| Packing List | Monitor × 1, Base component × 1, Power adapter (12 V, 2 A) × 1, HDMI cable (1.5 m) × 1, User manual × 1, Multilingual manual × 1 |
| Remarks | The base is included by default. The product appearance and parameters in this specification may vary from your actual device. Please consult our local sales staff for further information |
| Videos |
|---|
| No videos available |
| Files |
|---|
| Hikvision DS-D5024F2-BV2S Datasheet |
| Hikvision DS-D5024F2-BV2S Quick Start Guide |
| Hikvision DS-D5024F2-BV2S User Manual |
| Links* |
|---|
| Hikvision website |
| Hikvision support site |
