Brackenheath iSpot Swivel Floodlight IP65 Twin 220-240V Black
- Swivel LED Floodlight
- Frosted Diffuser
- 3-Year Guarantee
The Brackenheath BR3551 is an IP65 rated, stylish 2 x 8W 4000K outdoor twin floodlight with an adjustable swivel mount, and a modern frameless design (Read more)
PRODUCT DETAILS
The Brackenheath iSpot BR3551 is a stylish and compact 2 x 8W outdoor twin floodlight designed to provide reliable illumination for residential and commercial applications. Ideal for driveways, pathways, gardens, building entrances, car parks, and perimeter lighting, the iSpot combines a modern appearance with dependable performance and easy installation.
Featuring a fully adjustable swivel mounting bracket, the floodlight can be positioned precisely to direct light where it is needed most, making it suitable for both security and general-purpose outdoor lighting. Its contemporary design is complemented by a durable black plastic housing, providing excellent protection against everyday wear and harsh weather conditions.
With an IP65 weatherproof rating, the iSpot is protected against dust ingress and low-pressure water jets, making it suitable for year-round outdoor use. An integrated 220–240V driver and condensation release valve help maintain reliable performance and extend the product's service life, while the supplied power flex simplifies installation.
Features:
- Advanced LED floodlight designed for residential outdoor lighting
- 2 x 8W, 1920lm (120 lm/W), 4000K (Cool White), 4kV surge protection, CRI= 80, Beam 100°, IP65, 220–240V
- Twin heads with frosted diffuser and adjustable pan and tilt
- Polycarbonate housing and aluminium heads ensure corrosion-resistant protection
- Interchangeable across the iSpot outdoor family with shared backplate fixing holes
- Non-sensor floodlights can be controlled in series when linked to PIR Photocell floodlights (BR3552/BR3553)
- Suitable for wall or eaves mounting
- IP65 rating for total protection against dust and low pressure jets of water from any direction
- 3-year guarantee
| Specifications |
|
| Adjustability |
Rotatable |
| Beam angle |
Extreme wide beam >80° |
| Beam angle adjustable |
No |
| Colour consistency (McAdam
ellipse) |
SDCM6 |
| Colour of light |
White |
| Colour rendering index (CRI/Ra) |
80-89 |
| Colour temperature |
3700 - 4300K |
| Colour temperature switchable |
No |
| Compliance |
EN 60598-1:2021+A11:2022 EN60598-2-1:2021 |
| Conductor cross section |
2.5mm² |
| Connectable conductor cross section |
0.5 - 2.5mm² |
| Connection type |
Screwless terminal |
| Constant luminous flux control |
Yes |
| Containing product according to 2019/2020/EU |
Yes |
| Control gear |
LED driver constant current |
| Control gear included |
Yes |
| Cover material |
Other |
| Cut-out diameter |
0mm |
| Degree of protection (IP), front side |
IP65 |
| Degree of protection (IP), rear side |
Other |
| Degree of protection (NEMA) |
3 |
| Emergency function monitoring system |
None |
| Emergency power supply system |
None |
| Energy efficiency class of light source according to EU
regulation 2019/2015 |
E |
| Failure rate at median useful life of 100,000 hrs at 25 °C
ambient (tq) |
10% |
| Failure rate at median useful life of 35,000 hrs at 25 °C
ambient (tq) |
10% |
| Failure rate at median useful life of 50,000 hrs at 25 °C
ambient (tq) |
10% |
| Filament test according to IEC 60695-2-11 |
650 C - 30 s |
| Flickering value Pst LM |
1 |
| Height/depth |
99mm |
| Housing colour |
Black |
| Housing material |
Plastic |
| Impact resistance (IK rating) |
IK05 |
| Installation height |
0mm |
| Lamp cap/base |
None |
| Lamp power |
14.4 - 17.6W |
| Length |
164mm |
| Light diffuser type |
Diffuser |
| Light distribution |
Symmetric |
| Light outlet |
Direct/indirect |
| Light source included |
Yes |
| Light source type |
LED non-replaceable |
| Lumen maintenance (35,000 h at 25 °C) |
79.74% |
| Lumen maintenance at median useful life of 100,000 hr at 25 °C
ambient (tq) |
54.87% |
| Lumen maintenance at median useful life of 50,000 hrs at 25 °C
ambient (tq) |
73.15% |
| Lumen setting adjustable |
No |
| Luminaire efficacy |
78.75 - 125lm/W |
| Luminaire with limited surface temperature, class "D“ in acc.
with EN 60598-2-24 |
Yes |
| Luminous flux in emergency operation |
0lm |
| Luminous intensity |
770 - 800cd |
| Max. number of luminaires per miniature circuit breaker
B16 |
207 |
| Max. number of luminaires per miniature circuit breaker
C16 |
207 |
| Maximum system power |
17.6W |
| Movement sensor/presence detector technology |
Other |
| Nominal current |
63 - 77mA |
| Nominal voltage |
207 - 253V |
| Number of lamps |
2 |
| Number of poles |
2 |
| Outer diameter |
0mm |
| Photobiological safety according to EN 62471 |
RG1 |
| Power consumption in emergency mode |
0W |
| Power factor |
0.9 |
| Protection class according to IEC 61140 |
II |
| Rated ambient temperature acc. IEC62722-2-1 |
-20 - 40°C |
| Rated life time L70/B50 at 25 °C |
35000h |
| Rated luminous flux according to IEC 62722-2- 1 |
1260 - 2000lm |
| Recess length |
0mm |
| Recess width |
0mm |
| Reflector |
High-gloss |
| Reflector colour |
White |
| Stroboscope effect value SVM |
2.8 |
| Suitable for wall mounting |
Yes |
| Surface protection |
Untreated |
| Total harmonic distortion (THD) |
10% |
| Type of cabling |
Ending |
| Unified Glare Rating (UGR) |
22 |
| Voltage type |
AC |
| Width |
125mm |
