Brackenheath iSpot Swivel Floodlight IP65 with PIR Single 220-240V Black
Brackenheath
- Swivel LED Floodlight
- Frosted Diffuser
- Integrated PIR
The Brackenheath BR3552 is an IP65 rated 10W 4000K outdoor floodlight with an integrated PIR, adjustable swivel mount, and a modern frameless design (Read more)
PRODUCT DETAILS
The Brackenheath iSpot BR3552 is a stylish and compact 10W outdoor PIR floodlight designed to provide reliable illumination for residential and commercial applications. Ideal for driveways, pathways, gardens, building entrances, car parks, and perimeter lighting, the iSpot combines a modern appearance with dependable performance and easy installation.
Featuring a fully adjustable swivel mounting bracket, the floodlight can be positioned precisely to direct light where it is needed most, making it suitable for both security and general-purpose outdoor lighting. Non-sensor floodlights (BR3550/BR3551) can be controlled in series when linked to this PIR Photocell floodlight.
Its contemporary design is complemented by a durable black plastic housing, providing excellent protection against everyday wear and harsh weather conditions.
With an IP65 weatherproof rating, the iSpot is protected against dust ingress and low-pressure water jets, making it suitable for year-round outdoor use. An integrated 220–240V driver and condensation release valve help maintain reliable performance and extend the product's service life, while the supplied power flex simplifies installation.
Features:
- Advanced 3-in-1 LED Single Head Floodlight with twist-and-swivel PIR, Photocell, On/Off with manual override, ideal for residential use
- 8W, 960lm (120 lm/W), 4000K (Cool White), 4kV surge protection, CRI= 80, Beam 100°, IP65, 220–240V PIR 180° wide detection coverage up to 10m range
- Single head with frosted diffuser and adjustable pan and tilt
- Polycarbonate housing and aluminium heads ensure corrosion-resistant protection
- Interchangeable across the iSpot outdoor family with shared backplate fixing holes
- Non-sensor floodlights (BR3550/BR3551) can be controlled in series when linked to this PIR Photocell floodlight
- Suitable for wall or eaves mounting
- IP65 rating for total protection against dust and low pressure jets of water from any direction
- 3-year guarantee
| Specifications |
|
| Adjustability |
Rotatable |
| Beam angle |
Extreme wide beam >80° |
| Beam angle adjustable |
No |
| Colour consistency (McAdam
ellipse) |
SDCM6 |
| Colour of light |
White |
| Colour rendering index (CRI/Ra) |
80-89 |
| Colour temperature |
3700 - 4300K |
| Colour temperature switchable |
No |
| Compliance |
EN 60598-1:2021+A11:2022 EN60598-2-1:2021 |
| Conductor cross section |
2.5mm² |
| Connectable conductor cross section |
0.5 - 2.5mm² |
| Connection type |
Screwless terminal |
| Constant luminous flux control |
Yes |
| Containing product according to 2019/2020/EU |
Yes |
| Control gear |
LED driver constant current |
| Control gear included |
Yes |
| Cover material |
Other |
| Cut-out diameter |
0mm |
| Degree of protection (IP), front side |
IP65 |
| Degree of protection (IP), rear side |
Other |
| Degree of protection (NEMA) |
3 |
| Emergency function monitoring system |
None |
| Emergency power supply system |
None |
| Energy efficiency class of light source according to EU
regulation 2019/2015 |
E |
| Failure rate at median useful life of 100,000 hrs at 25 °C
ambient (tq) |
10% |
| Failure rate at median useful life of 35,000 hrs at 25 °C
ambient (tq) |
10% |
| Failure rate at median useful life of 50,000 hrs at 25 °C
ambient (tq) |
10% |
| Filament test according to IEC 60695-2-11 |
650 C - 30 s |
| Flickering value Pst LM |
1 |
| Height/depth |
99mm |
| Housing colour |
Black |
| Housing material |
Plastic |
| Impact resistance (IK rating) |
IK05 |
| Installation height |
0mm |
| Lamp cap/base |
None |
| Lamp power |
7.65 - 9.35W |
| Length |
80mm |
| Light diffuser type |
Diffuser |
| Light distribution |
Symmetric |
| Light outlet |
Direct/indirect |
| Light source included |
Yes |
| Light source type |
LED non-replaceable |
| Lumen maintenance (35,000 h at 25 °C) |
79.74% |
| Lumen maintenance at median useful life of 100,000 hr at 25 °C
ambient (tq) |
54.87% |
| Lumen maintenance at median useful life of 50,000 hrs at 25 °C
ambient (tq) |
73.15% |
| Lumen setting adjustable |
No |
| Luminaire efficacy |
74.12 - 117.65lm/W |
| Luminaire with limited surface temperature, class "D“ in acc.
with EN 60598-2-24 |
Yes |
| Luminous flux in emergency operation |
0lm |
| Luminous intensity |
385 - 400cd |
| Max. number of luminaires per miniature circuit breaker
B16 |
310 |
| Max. number of luminaires per miniature circuit breaker
C16 |
310 |
| Maximum system power |
9.35W |
| Movement sensor/presence detector technology |
Other |
| Nominal current |
42.5 - 51.5mA |
| Nominal voltage |
207 - 253V |
| Number of lamps |
1 |
| Number of poles |
3 |
| Outer diameter |
0mm |
| Photobiological safety according to EN 62471 |
RG1 |
| Power consumption in emergency mode |
0W |
| Power factor |
0.7 |
| Protection class according to IEC 61140 |
II |
| Rated ambient temperature acc. IEC62722-2-1 |
-20 - 40°C |
| Rated life time L70/B50 at 25 °C |
35000h |
| Rated luminous flux according to IEC 62722-2- 1 |
630 - 1000lm |
| Recess length |
0mm |
| Recess width |
0mm |
| Reflector |
High-gloss |
| Reflector colour |
White |
| Stroboscope effect value SVM |
2.8 |
| Suitable for wall mounting |
Yes |
| Surface protection |
Untreated |
| Total harmonic distortion (THD) |
10% |
| Type of cabling |
Ending |
| Unified Glare Rating (UGR) |
22 |
| Voltage type |
AC |
| Width |
125mm |
| With light sensor |
Yes |
| With movement sensor |
Yes |
