Planet POE-2400G 24 Port 802.3at Managed Injector
fullscreen
  • Planet POE-2400G 24 Port 802.3at Managed Injector

Planet POE-2400G 24 Port 802.3at Managed Injector

Planet Planet

  • Fully managed
  • 24 x PoE+ Gigabit
  • Max 400W budget
Full description
FREE delivery is available for this product    24 Months warranty    69 reward points
£358.63
£298.86 Ex VAT
AvailabilityLow stock
More stock due21/10/2019
Delivery From FREE* Inc VAT
Product Code12369
Model NumberPOE-2400G
DELIVERY
Next day delivery available.
Order before 15:00 for delivery from
Wednesday 23rd October
Qty Ex VAT Inc VAT
1+£298.86£358.63

Planet POE-2400G 24 Port Gigabit 802.3at Managed Injector Hub

The Planet POE-2400G is a managed 24 port PoE injector hub that has 24 Gigabit PoE+ (802.3at) ports for powering PoE devices at up to 30W per port to a maximum of 400W across all ports.

The POE-2400G has 24 input ports and 24 output ports which makes it a simple solution to add PoE to an existing network switch that doesn't have PoE. All 24 ports are Gigabit ensuring no loss of performance across the hub.



Managed PoE

The simple to use web based management interface allows you to enable or disable PoE per port making it simple to remotely reboot devices to resolve issues. It also allows you to schedule PoE power as well as monitor device status and overall power usage.


PoE Device Monitoring

For critical application such as surveillance the POE-2400G can be used to monitor attached devices and automatically cycle the power if the device becomes unresponsive. This greatly improves system reliability and reduces the work of a system administrator.


PoE Scheduling

PoE Scheduling enables system administrators to easily create schedules to ensure PoE powered devices are only powered when required. This can be useful for powering down non-essential PoE devices at times when they are not required and saving energy as a result.


Features

  • 24 x 10/100/1000 PoE+ (802.3af) input/output ports
  • Fully web managed for advanced control of PoE devices
  • Large 440W overall power budget
  • Monitor and reboot non-responsive PoE devices automatically
  • PoE Scheduling for energy saving
  • 19" Rack mountable
  • Silent and efficient operation
Hardware
Power over Ethernet
Management
Standards Conformance
Environments
Hardware Version 4
Interface Data Input Ports: 24 x RJ45
Data+Power Output Ports: 24 x RJ45
Management Port: 1 x RJ45; 10/100/1000BASE-T, auto-negotiation, auto-MDI/MDIX
Data Rate 10/100/1000Mbps
LED System:
SYS PWR x 1 (Green)
PoE1 Failure x 1 ( Red )
PoE2 Failure x 1 ( Red )
Fan1 Failure x 1 ( Red )
Fan2 Failure x 1 ( Red )
Per PoE Port: PoE-in-use x 1 (Green)
Management port x 2: 1000 (Green), 10/100(Orange)
Network Cable 10BASE-T: 4-pair UTP Cat5 up to 100m (328ft)
100BASE-TX: 4-pair UTP Cat5 up to 100m (328ft)
1000BASE-T: 4-pair UTP Cat5e/6 up to 100m (328ft)
EIA/TIA- 568 100-ohm STP (100m)
Power Requirements 100-240V AC, 50/60 Hz, 8A
Power Consumption 500 watts (max.)
Ventilation Fan x 3
Dimensions (W x D x H) 440 x 300 x 44mm
PoE Power Supply Type Mid-span
PoE Power Output Per port DC 52V 30.8/15.4 watts
Power Pin Assignment 4/5(-), 7/8(+)
PoE Power Budget 440 watts
Number of 802.3af PDs (Class 0, 1, 2, 3) can be powered 24
Number of 802.3at PDs (Class 1, 2, 3) can be powered 14
Number of 802.3at PDs (Class 0, 4) can be powered 14
Management Interface Web, PLANET Smart Discovery Lite
PoE Management Power limit by consumption and classification mode
PoE admin mode
Per port power schedule
Per port power enable/disable
Power feeding priority
Over temperature protection
Current per port usage and status
Total power consumption
Management Feature Setup of system/management functions
Web firmware upgrade
SNMP trap for alarm notification of events
Regulatory Compliance FCC Part 15 Class A, CE
Standards Compliance IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
IEEE 802.3at Power over Ethernet Plus
IEEE 802.3af Power over Ethernet
RFC 768: UDP
RFC 791: IP
RFC 2068 HTTP
RFC 1157: SNMP v1
RFC 1902: SNMP v2c
RFC 5424: Syslog
Operating Temperature: 0 ~ 50 degrees C
Relative Humidity: 5 ~ 90% (non-condensing)
Storage Temperature: -10 ~ 70 degrees C
Relative Humidity: 5 ~ 90% (non-condensing)
