Hikvision DS-3E1510P-EI DS-3E1510P-EI(O-STD)V2 8-Port Gigabit PoE Managed Switch
Hikvision
- Gigabit Speed
- PoE Managed
- 3 year guarantee
The Hikvision DS-3E1510P-EI is a high-performance, professional network 8-port Gigabit PoE (Power over Ethernet) managed switch (Read more)
PRODUCT DETAILS
The Hikvision DS-3E1510P-EI is a high-performance, 8-port Gigabit PoE (Power over Ethernet) managed switch, designed for professional network installations that demand both speed and reliability. Ideal for powering IP cameras, wireless access points, and other PoE-enabled devices, it combines robust management features with exceptional throughput.
Features:
- 8 × Gigabit PoE port,2 × Gigabit RJ45 port
- Total PoE Power Budget 110W
- Support 802.1Q VLAN
- Support PoE watchdog to detect and restart the cameras that do not respond
- Support STP/RSTP Loop prevention
- Support cable detection to locate failure
- Up to 300 m Long Range PoE Transmission
- 6KV Surge Protection
Specifications
| Model | DS-3E1510P-EI |
|---|---|
| Ports | 8 × Gigabit PoE port, 2 × Gigabit RJ45 port |
| MAC Address Table | 4K |
| Switching Capacity | 20 Gbps |
| Packet Forwarding Rate | 14.88 Mpps |
| Internal Cache | 1.5 Mbits |
| PoE Standard | IEEE 802.3af, IEEE 802.3at |
| PoE Power Pin | End-span: 1/2(-), 3/6(+) |
| PoE Port | Ports 1 to 8 |
| Max. Port Power | 30 W |
| PoE Power Budget | 110 W |
| Long Range | Ports 1–8: up to 300 m (performance may vary with camera model/cable) |
| Port Isolation | Ports 1–8: isolation mode prevents communication within group but allows external communication |
| PoE Watchdog | Ports 1–8 auto detect and restart unresponsive cameras |
| Link Aggregation | Supports static link aggregation, load balancing, and protection. Supports 3 aggregation groups. |
| Loop Prevention | Supports 802.1D STP & 802.1w RSTP; disabled by default. |
| VLAN | Supports 802.1Q, VLAN ID 1–4094, Trunk/Access mode, up to 32 VLANs. |
| HPP | One-click activation via Hik-Partner Pro:
|
| System Maintenance | Web device management, DHCP Client (enabled by default), fixed Super IP (10.180.190.200), SNMP v1/v2c, LLDP, port mirroring. |
| Dimensions (W × H × D) | 217.6 × 27.6 × 108.5 mm (8.57″ × 1.09″ × 4.27″) |
| Storage Temperature | -40 °C to 85 °C (-40 °F to 185 °F) |
| Installation Mode | Desk-mounted, Wall-mounted |
| Gross Weight | 1.27 kg (2.8 lb) |
| Net Weight | 0.54 kg (1.19 lb) |
| Power Consumption (Idle) | 2.7 W |
| Shell | Metal |
| Operating Temperature | 0 °C to 40 °C (32 °F to 104 °F) |
| Operating Humidity | 5% to 95% (no condensation) |
| Power Supply | 54 V DC, 2.22 A |
| Max. Power Consumption | 120 W |
| Relative Humidity | 5% to 95% (no condensation) |
| Surge Protection | 6 kV |
| EMC | CE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020) |
| Safety | CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 2nd Ed.), CE-LVD (EN 62368-1: 2014+A11: 2017) |
| Chemistry | CE-RoHS (2011/65/EU), WEEE (2012/19/EU), REACH (Regulation (EC) No.1907/2006) |
| Videos |
|---|
| No videos available |
| Files |
|---|
| Hikvision DS-3E1510P-EI Datasheet |
| Hikvision DS-3E1510P-EI Quick Start Guide |
| Hikvision DS-3E1510P-EI User Manual |
| Links* |
|---|
| Hikvision website |
| Hikvision support site |
