Samsung 250GB 870 EVO SSD, 2.5", SATA3, V-NAND, R/W, 560/530 MB/s, 98K/88K, 7mm
- Fast Data Transfer
- Shock Proof
- 5 year guarantee
The Samsung 870 EVO range of high-quality 2.5” SATA solid state drives are designed for fast, reliable storage in PCs, servers, and security systems. (Read more)
PRODUCT DETAILS
The Samsung 870 EVO range of high-quality 2.5” SATA solid state drives are designed for fast, reliable storage upgrades in PCs, servers, and security systems. For CCTV installations, 870 EVO SSDs are an excellent choice for NVR and DVR installs where responsiveness and reliability matter.
With SATA III (6Gb/s) performance and a proven SSD controller platform, the 870 EVO helps reduce boot times, speed up playback and scrubbing, and improve system stability—especially on CCTV systems running multiple services (recording + analytics + remote access). The new and improved Samsung Magician 6 software will keep your SSD in check. You can easily manage your drive with a wide range of useful tools to keep up with the latest updates, monitor the drive's health and status, or even enhance its performance.
SSD's (Solid State Drives) offer faster read/write speeds, consume less power, generate less heat, and are more shock-resistant than standard hard drives. As they have no moving parts, SSD's tend to last longer than HDD's also.
Features:
- 2.5” SATA SSD (SATA III 6Gb/s) – straightforward upgrade for most NVR/DVR and PC-based VMS systems
- High speed for SATA storage – ideal for snappy system performance and video review
- Low power / low heat – helps reduce system load in always-on CCTV environments
- No moving parts – silent operation and improved resistance to vibration compared to HDDs
- Multiple capacities to suit OS-only builds or larger performance storage requirements
| Specifications | 250GB | 500GB | 1TB | 2TB |
|---|---|---|---|---|
| Capacity |
250 GB (1 GB=1 Billion
byte by IDEMA) * Actual usable capacity may be less (due to
formatting, partitioning, operating system, applications or
otherwise) |
500 GB (1 GB=1 Billion
byte by IDEMA) * Actual usable capacity may be less (due to
formatting, partitioning, operating system, applications or
otherwise) |
1,000 GB (1 GB=1 Billion
byte by IDEMA) * Actual usable capacity may be less (due to
formatting, partitioning, operating system, applications or
otherwise) |
2,000 GB (1 GB=1 Billion
byte by IDEMA) * Actual usable capacity may be less (due to
formatting, partitioning, operating system, applications or
otherwise) |
| Form Factor |
2.5
inch |
|||
| Interface |
SATA 6
Gb/s Interface, compatible with SATA 3 Gb/s & SATA 1.5 Gb/s
interface |
|||
| Dimension (WxHxD) |
100 X
69.85 X 6.8 (mm) |
|||
| Weight |
Approx.
45.0g Weight |
|||
| Storage Memory |
Samsung
V-NAND 3bit MLC |
|||
| Controller |
Samsung
MKX Controller |
|||
| Cache Memory |
Samsung 512 MB Low
Power DDR4 SDRAM |
Samsung 512 MB Low
Power DDR4 SDRAM |
Samsung 1 GB Low Power
DDR4 SDRAM |
Samsung 2 GB Low Power
DDR4 SDRAM |
| Sequential Read |
Up to
560 MB/s Sequential Read * Performance may vary based on system
hardware & configuration |
|||
| Sequential Write |
Up to
530 MB/s Sequential Write * Performance may vary based on system
hardware & configuration ** Measured with Intelligent
TurboWrite technology being activated |
|||
| Random Read (4 KB, QD32) |
Up to
98,000 IOPS Random Read * Performance may vary based on system
hardware & configuration ** Measured with Intelligent
TurboWrite technology being activated |
|||
| Random Write (4KB, QD32) |
Up to
88,000 IOPS Random Write * Performance may vary based on system
hardware & configuration ** Measured with Intelligent
TurboWrite technology being activated |
|||
| Random Read (4 KB, QD1) |
Up to
13,000 IOPS Random Read * Performance may vary based on system
hardware & configuration ** Measured with Intelligent
TurboWrite technology being activated |
|||
| Random Write (4 KB, QD1) |
Up to
36,000 IOPS Random Write * Performance may vary based on system
hardware & configuration ** Measured with Intelligent
TurboWrite technology being activated |
|||
| Average Power Consumption (system level) |
Average: 2.2 W
*Maximum: 3.5 W (Burst mode)* Actual power consumption may vary
depending on system hardware & configuration |
Average: 2.2 W
*Maximum: 3.5 W (Burst mode)* Actual power consumption may vary
depending on system hardware & configuration |
Average: 2.5 W *Maximum: 4.0 W (Burst
mode)* Actual power consumption may vary depending on system
hardware & configuration |
Average: 2.5 W *Maximum: 4.5 W (Burst
mode)* Actual power consumption may vary depending on system
hardware & configuration |
| Power consumption (Idle) |
Max. 30 mW * Actual
power consumption may vary depending on system hardware &
configuration |
Max. 30 mW * Actual
power consumption may vary depending on system hardware &
configuration |
Max. 30 mW * Actual
power consumption may vary depending on system hardware &
configuration |
Max. 35 mW * Actual power consumption may
vary depending on system hardware & configuration |
| Allowable Voltage |
5V ± 5%
Allowable voltage |
|||
| Reliability (MTBF) |
1.5
Million Hours Reliability (MTBF) |
|||
| Operating Temperature |
0 - 70
℃ Operating Temperature |
|||
| Shock |
1,500 G
& 0.5 ms (Half sine) |
|||
| Management SW |
Magician
Software for SSD management, Data Migration Software for SSD
upgrade |
|||
| TRIM Support |
TRIM
Supported |
|||
| S.M.A.R.T Support |
S.M.A.R.T
Supported |
|||
| GC (Garbage Collection) |
Auto
Garbage Collection Algorithm |
|||
| Encryption Support |
AES
256-bit Encryption (Class 0),TCG/Opal, IEEE1667 (Encrypted
drive) |
|||
| WWN Support |
World
Wide Name supported |
|||
| Device Sleep Mode Support |
Yes |
|||
| Warranty |
5 Years Limited Warranty or 150 TBW Limited
Warranty |
5 Years Limited Warranty or 300 TBW Limited
Warranty |
5 Years Limited Warranty or 600 TBW Limited
Warranty |
5 Years Limited Warranty or 1,200 TBW
Limited Warranty |
| Videos |
|---|
| No videos available |
| Files |
|---|
| No files available |
| Links* |
|---|
| Samsung website |
| Samsung support site |
