Ruijie RG-M32 3200Mbps Wi-Fi 6 Dual-band Gigabit Mesh Router
Ruijie
- Wi-Fi 6 Standard
- 4 Dual-Band Antennas
- 3 year guarantee
The Ruijie RG‑M32 is a high‑performance Wi‑Fi 6 (802.11ax) dual‑band mesh router designed to deliver ultra‑fast and stable Wi-Fi over large areas. (Read more)
PRODUCT DETAILS
The Ruijie RG‑M32 is a high‑performance Wi‑Fi 6 (802.11ax) dual‑band mesh router designed to deliver ultra‑fast, stable, and wide‑area wireless coverage for modern homes and small offices. With combined speeds of up to 3200Mbps and mesh networking capability, it ensures seamless connectivity across multiple rooms and floors - perfect for high‑demand internet use, streaming, gaming, and smart home devices.
Featuring 2.4GHz (800Mbps) and 5GHz (2400Mbps) dual‑band operation, the RG‑M32 offers higher capacity, reduced latency, and improved efficiency compared to previous‑generation Wi‑Fi standards. The powerful Quad‑Core CPU ensures smooth handling of multiple simultaneous connections, while Gigabit Ethernet ports provide high‑speed wired connectivity for desktop PCs, gaming consoles, or network storage devices.
When combined with other Ruijie Reyee mesh routers, the RG‑M32 automatically forms a self‑organising mesh network, delivering uninterrupted roaming as you move between coverage areas. Setup and management are simple via the Reyee Router mobile app, allowing quick installation, parental controls, and network monitoring from anywhere.
Features:
- Next-gen gigabit Wi-Fi 6 standard
- 4x4 Enterprise-level chipset, better stability under heavy load
- 4 Dual-band antennas and 8 signal amplifiers, provide whole-home network coverage
- Exclusive Reyee Mesh solution, one click to mesh up multiple Reyee Mesh devices
- Smart signal indicator, find the best spot to place a sub-router
- Take control of your home network at your fingertips
| Specifications |
|
| Dimensions (W×D×H） |
119 mm × 119 mm × 200 mm (4.7 in. × 5 in. × 7.9 in. antennas not included) |
| Weight |
0.66 kg (packages not included) |
| Wi-Fi Standards |
Wi-Fi 6 (802.11ax) |
| MIMO |
2.4 GHz, 4×4, MU-MIMO 5 GHz, 4×4, MU-MIMO |
| Max. Wi-Fi Speed |
2.4 GHz: 800Mbps 5 GHz: 2402Mbps |
| Channel Width |
2.4 GHz: Auto/20/40 MHz 5 GHz: Auto/20/40/80MHz |
| Antennas |
4 dual-band |
| Antennas Type |
Internal Omnidirectional |
| Antenna Gain |
2.4 GHz: 4 dBi 5 GHz: 4 dBi |
| WAN Port |
1×10/100/1000 Base-T |
| LAN Ports |
3×10/100/1000 Base-T |
| Recommended Users |
60 |
| Max. Users |
192 |
| Power Supply |
DC 12V/2A |
| Power Consumption |
≤ 30 W |
| Operation Frequency Bands |
802.11b/g/n/ax: 2.400 GHz to 2.483 GHz 802.11a/n/ac: 5.150 GHz to 5.350 GHz 802.11a/n/ac/ax: 5.470 GHz to 5.725 GHz , 5.725 GHz to 5.850 GHz country-specific restrictions apply |
| DFS |
Support |
| Transmit Power |
European Union & United Kingdom 2400-2483.5 MHz, EIRP≤ 20 dBm 5150-5350 MHz, EIRP≤ 23 dBm 5470-5725 MHz, EIRP≤ 30 dBm United States: 2400-2483.5 MHz, max output power≤30dBm & EIRP ≤ 36 dBm 5150-5250 MHz, max output power≤30dBm & EIRP ≤ 36 dBm 5250-5350 MHz, max output power<24dBm & EIRP ≤ 30 dBm 5470-5725 MHz, max output power<24dBm & EIRP ≤ 30 dBm 5725-5850 MHz, max output power≤30dBm & EIRP ≤ 36 dBm Myanmar : 2400-2483.5 MHz, EIRP ≤ 23 dBm 5725-5825 MHz, EIRP ≤ 30 dBm Thailand: 2400-2483.5 MHz, EIRP ≤ 20 dBm 5150-5350 MHz, EIRP ≤ 23 dBm 5470-5725 MHz, EIRP ≤ 30 dBm 5725-5825 MHz, EIRP ≤ 30 dBm Indonesia: 2400-2483.5 MHz, EIRP ≤ 27 dBm 5150-5350 MHz, EIRP ≤ 23 dBm 5725-5825 MHz, EIRP ≤ 23 dBm Egypt： 2400-2483.5 MHz, EIRP ≤ 20 dBm 5150-5350 MHz, EIRP ≤ 23 dBm |
| Receive Sensitivity |
2.4 GHz: 802.11b: -96 dBm(1 Mbps) 802.11g: -91 dBm(6 Mbps), -85 dBm(54 Mbps) 802.11n: -90dBm(MCS0), -85 dBm(MCS7) 5 GHz: 802.11n: -90 dBm(MCS0), -70 dBm(MCS7) 802.11a: -88 dBm(6 Mbps), -60 dBm(54 Mbps) 802.11ac: -82dBm(MCS0), -57dBm(MCS7), -52dBm(MCS9) |
| Operating Temperature |
-10 °C to +40 °C (14 °F to 104 °F) |
| Operating Humidity |
5% to 95% Noncondensing |
| Certifications |
CE, SIRIM, RCM RoHS |
| Wireless |
|
| OFDMA |
Support |
| MU-MIMO |
Support |
| BSS Colouring |
Support |
| Maximum Number of SSIDs |
6 |
| SSID Hiding |
Support |
| Band Steering |
Support |
| Guest Wi-Fi |
Support |
| WPA/WPA2 |
Support |
| WPA3 |
- |
| Roaming |
Layer 3 Roaming |
| Blocklist |
Support |
| Reyee Mesh |
Support |
| Mesh Pairing by Hardware |
Support |
| Mesh Pairing by Mesh Button |
Support |
| Mesh Pairing by Eweb |
Support |
| Recommended Hop Count |
≤2 |
| Wi-Fi Optimization |
Support |
| QoS (WMM) |
Support |
| WPS |
- |
| Transmission Power Adjustment |
Support |
| Hardware |
|
| CPU |
MT7622B+MT7911AN+MT7915AN |
| Flash |
16 MB |
| RAM/SDRAM |
256 MB |
| Colour |
Black |
| System LED Indicator |
Support |
| Reyee Mesh LED Indicator |
Support |
| Reyee Mesh Button |
Support |
| Power Button |
- |
| Reset Button |
Support |
| DC Connector Dimensions |
Outer Diameter: 5.5 mm Inner Diameter: 2.0 mm Length: 11.5 mm (Outer Diameter: 0.22 in. Inner Diameter: 0.07 in. Length: 0.39 in. ) |
| WAN |
|
| Static IP |
Support |
| DHCP |
Support |
| PPPoE |
Support |
| Learning PPPoE Account & Password |
Support |
| VLAN Tagging |
Support |
| LAN |
|
| DHCP Server |
Support |
| Client List |
Support |
| Static IP Assignment |
Support |
| Port-Based Flow Control |
Support |
| Features |
|
| TR069 |
Support |
| Preset |
Support |
| IPv6 |
Support |
| DDNS |
Support |
| IPTV |
Support |
| Alarm |
Support |
| Diagnosis |
Support |
| UPnP |
Support |
| ARP Binding |
Support |
| Port Mapping |
Support |
| DMZ Host |
Support |
| Rate Limitation of Terminals |
Support |
| Hardware Acceleration |
Support |
| MAC Address Cloning |
Support |
| Cloud Management |
Support |
| Repeater Mode |
Support |
| WISP Mode |
Support |
| AP Mode |
Support |
| Security |
|
| PPTP VPN Server |
Support |
| PPTP VPN Client |
Support |
| L2TP VPN Client |
- |
| Parental Control |
Time Schedule |
| Protect TCP Flood Attacks |
Support |
| Protect ICMP Attacks |
- |
| Protect UDP Flood Attacks |
- |
| System |
|
| Default Access/Password |
192.168.110.1 No Password Required by Default |
| URL Access |
Support |
| Local Upgrade |
Support |
| Online Upgrade |
Support |
| APP Upgrade |
Support |
| Syslog |
Support |
| Backup |
Support |
| Factory Reset |
Support |
| Language |
Chinese English Vietnamese Indonesian Thai Arabic Traditional Chinese Spanish Russian |
| Package Contents |
|
| Wireless Router |
1 |
| Power Adapter |
1 |
| Quick Start Guide |
1 |
| Warranty Card |
1 |
| Cat5E UTP Cable |
1 |
| Videos |
|---|
Reyee Mesh Solution Video
Ruijie Easy Network Solution| Files |
|---|
| Ruijie RG-M32 Datasheet |
| Ruijie RG-M32 Installation Guide |
| Ruijie RG-M32 User Manual |
| Links* |
|---|
| Ruijie website |
| Ruijie support site |
