Ruijie RG-EW1200R Reyee Dual-band Mesh 802.11ac 1200Mbps Wi-Fi Extender
Ruijie
- Signal Indicator
- Dual Band
- 3 year guarantee
The Ruijie RG-EW1200R Reyee is a Plug-in dual band mesh Wi-Fi Extender with dual antennas which offer up to 1200 Mbps data rate on Wi-Fi 5 (802.11ac) (Read more)
PRODUCT DETAILS
The Ruijie RG-EW1200R is a dual-band plug-in Wi-Fi extender with dual antennas which offer up to 1200 Mbps data rate on Wi-Fi 5 (802.11ac). The RG-EW1200R can provide larger Wi-Fi coverage, as well as extremely fast data rate, providing playback of 4K videos, massively multiplayer online games, and high-speed downloads.
The RG-EW1200R features a three-bar LED signal indicator which clearly shows you the signal strength and guides you to the best spot to position the repeater. A home network can be set up in the Reyee Router App in two minutes and provides features such as remote management, parental control, smart home controls and guest Wi-Fi.
Features:
- Cover your whole home network with one-click
- Built-in signal amplifiers, unbreakable Wi-Fi signal throughout your home
- Three-bar signal indicator guides you to find the best spot
- Reyee Mesh brings you unlimited signal connection everywhere you go
- More wireless mode options, more surprise
- Take control of your home network at your fingertips
| Basic | |
| Dimensions (W×D×H) |
128 mm x 102 mm x 60 mm (5.04 in. × 4.02 in. × 2.36 in. antennas not included) |
| Weight |
0.25 kg (packages not included) |
| Wi-Fi Standards |
Wi-Fi 5 (802.11ac) |
| MIMO |
2.4 GHz, 2×2, MU-MIMO 5 GHz, 2×2, MU-MIMO |
| Max. Wi-Fi Speed |
2.4 GHz: 300 Mbps 5 GHz: 867 Mbps |
| Channel Width |
2.4 GHz: Auto/20/40 MHz 5 GHz: Auto/20/40/80 MHz |
| Antennas |
2 |
| Antennas Type |
External Omnidirectional |
| Antenna Gain |
2.4 GHz: 4 dBi 5 GHz: 4 dBi |
| Port |
1×10/100 Base-T WAN/LAN |
| Recommended Users |
24 |
| Max. Users |
96 |
| Power Supply |
100-240V~50/60Hz 0.5A |
| Power Consumption |
≤15W |
| Operation Frequency Bands |
802.11b/g/n/: 2.400 GHz to 2.483 GHz 802.11a/n/ac: 5.150 GHz to 5.350 GHz 802.11a/n/ac: 5.470 GHz to 5.725 GHz, 5.725 GHz to 5.850 GHz country-specific restrictions apply |
| Transmit Power |
Regular: CE EIRP: ≤20dBm (2.4GHz) ≤27dBm (5GHz) ≤20dBm 2400~2483.5MHz (Bluetooth) Myanmar: 2400~2483.5MHz ≤ 20dBm (EIRP) ; 5150~5350MHz ≤ 23dBm (EIRP) ; 5470~5725MHz ≤ 30dBm (EIRP) ; 5725~5850MHz ≤ 30dBm (EIRP) ; |
| Operating Temperature |
-10 °C to +45 °C (14 °F to 113 °F) |
| Operating Humidity |
5% to 95% Noncondensing |
| Certifications |
CE, RoHS |
| Wireless |
|
| OFDMA |
- |
| MU-MIMO |
Yes |
| BSS Colouring |
- |
| Maximum Number of SSIDs |
6 |
| SSID Hiding |
Yes |
| Band Steering |
Yes |
| Guest Wi-Fi |
Yes |
| WPA/WPA2 |
Yes |
| WPA3 |
- |
| Roaming |
Layer 2 Roaming |
| Blacklist |
Yes |
| Reyee Mesh |
Yes |
| Mesh Pairing by Hardware |
Yes |
| Mesh Pairing by Mesh Button |
Yes |
| Mesh Pairing by Eweb |
Yes |
| Recommended Hop Count |
≤2 |
| Wi-Fi Optimization |
Yes |
| QoS (WMM) |
Yes |
| WPS |
Yes |
| Transmission Power Adjustment |
Yes |
| Hardware |
|
| CPU |
MT7628DAN |
| Flash |
16 MB |
| RAM/SDRAM |
64 MB |
| Colour |
White |
| System LED Indicator |
Yes |
| Reyee Mesh LED Indicator |
Yes |
| Reyee Mesh Button |
Yes |
| Power Button |
- |
| Reset Button |
Yes |
| DC Connector Dimensions |
- |
| WAN |
|
| Static IP |
Yes |
| DHCP |
Yes |
| PPPoE |
Yes |
| Learning PPPoE Account & Password |
Yes |
| VLAN Tagging |
Yes |
| LAN |
|
| DHCP Server |
Yes |
| Client List |
Yes |
| Static IP Assignment |
Yes |
| Port-Based Flow Control |
Yes |
| Features |
|
| IPv6 |
- |
| DDNS |
- |
| IPTV |
- |
| Alarm |
- |
| Diagnosis |
- |
| UPnP |
- |
| ARP Binding |
- |
| Port Mapping |
- |
| DMZ Host |
- |
| Rate Limitation of Terminals |
- |
| Hardware Acceleration |
- |
| MAC Address Cloning |
Yes |
| Cloud Management |
Yes |
| Repeater Mode |
Yes |
| WISP Mode |
Yes |
| Security |
|
| PPTP VPN Server |
- |
| PPTP VPN Client |
- |
| L2TP VPN Client |
- |
| Parental Control |
- |
| Protect TCP Flood Attacks |
Yes |
| Protect ICMP Attacks |
- |
| Protect UDP Flood Attacks |
- |
| System |
|
| Default Access/Password |
10.44.77.254 No Password Required by Default |
| URL Access |
- |
| Local Upgrade |
Yes |
| Online Upgrade |
Yes |
| APP Upgrade |
Yes |
| Syslog |
- |
| Backup |
- |
| Factory Reset |
Yes |
| Language |
Chinese English Vietnamese Indonesian Thai Arabic Traditional Chinese Spanish Russian |
| Package Contents |
|
| Device |
RG-EW1200R |
| Wireless Extender |
1 |
| User Manual |
1 |
| Warranty card |
1 |
| Videos |
|---|
Ruijie RG-EW1200R
Reyee Mesh Solution Video
Ruijie Easy Network Solution| Files |
|---|
| Ruijie RG-EW1200R Datasheet |
| Links* |
|---|
| Ruijie website |
| Ruijie support site |
