Ruijie RG-RAP62 Wi-Fi 6 AX1800 Ceiling-Mount Access Point
Ruijie
- Dual Band
- 1775 Mbps
- 3 year guarantee
The Ruijie RG-RAP62 is a high-performance 1775Mbps Wi-Fi 6 AX1800 dual band Access Point, providing 574 Mbit/s at 2.4 GHz & 1201 Mbit/s at 5 GHz (Read more)
PRODUCT DETAILS
The Ruijie RG‑RAP62 is a high‑performance Wi‑Fi 6 (802.11ax) ceiling‑mount access point designed to deliver fast, stable, and high‑capacity wireless connectivity for business, education, hospitality, and enterprise networks. Supporting AX1800 dual‑band speeds and advanced wireless technologies, the RG‑RAP62 ensures seamless performance in high‑density environments.
Featuring dual‑band operation with speeds up to 574Mbps on 2.4GHz and 1201Mbps on 5GHz, this access point offers enhanced efficiency, reduced latency, and improved coverage—ideal for modern wireless networks where multiple devices are connected simultaneously.
Enjoy the benefits of the latest Wi-Fi 6 technology, offering faster speeds, increased capacity, and improved efficiency. With faster data transfer rates, the RG-RAP62 can support a larger number of devices, making it perfect for high-density environments.
Easy Set-Up
Self-Organizing Networking (SON) eliminates product limitations and realizes auto-discovery, auto-networking, and auto-configuration between routers, switches, and wireless APs without the need for controllers or Internet access. The mobile app allows you to quickly complete device deployment and configuration, remote management, operation and maintenance (O&M) of the entire network, which greatly reduces the investment of device, labour, and time cost during wireless network construction.
Features:
- Build ultra-fast network with Wi-Fi 6 technology.
- Client connections over 500, better multi-user experience.
- Provide higher practical performance for users as well.
- Easily install extra AP with Reyee Mesh technology.
- Set up Wi-Fi 6 network in 3 minutes with Ruijie Cloud APP.
| Hardware | |
| Wi-Fi Protocols |
5 GHz Wi-Fi 4: IEEE 802.11a/n Wi-Fi 5: IEEE 802.11ac Wave2 Wi-Fi 6: IEEE 802.11ax 2.4 GHz Wi-Fi 4:IEEE 802.11b/g/n Wi-Fi 6:IEEE 802.11ax |
| Operating Frequency Bands (country-specific restrictions apply) |
5 GHz 5.150 GHz to 5.350 GHz, 5.470 GHz to 5.725 GHz, 5.725 GHz to 5.850 GHz 2.4 GHz 2.400 GHz to 2.4835 GHz |
| Spatial Streams |
5 GHz 2 spatial streams, 2x2 MIMO 2.4 GHz 2 spatial streams, 2x2 MIMO |
| Antenna |
|
| Omni-directional |
Yes |
| 5 GHz Antenna Gain |
3.0dBi |
| 2.4 GHz Antenna Gain |
3.0dBi |
| Channel Width |
|
| 5 GHz |
Auto/20/40/80 MHz |
| 2.4 GHz |
Auto/20/40 MHz |
| Data Rate |
|
| Max Throughput |
1774Mbps |
| 5 GHz |
1201Mbps |
| 2.4 GHz |
573Mbps |
| Max. Transmit
Power |
|
| 5 GHz |
≤200mW(23dBm) |
| 2.4 GHz |
≤200mW(23dBm) |
| Modulation |
|
| Modulation |
OFDM: BPSK@6/9 Mbps, QPSK@12/18 Mbps,
16QAM@24 Mbps, 64QAM@48/54 Mbps DSSS: DBPSK@1 Mbps, DQPSK@2 Mbps, and CCK@5.5/11 Mbps MIMO-OFDM: BPSK, QPSK, 16QAM , 64QAM, 256QAM and 1024QAM OFDMA |
| Receiver
Sensitivity |
|
| Receiver Sensitivity |
11b: -91dBm(1Mbps)，-88dBm(5.5Mbps)，-
85dBm(11Mbps) 11a/g: -89dBm(6Mbps)，-80dBm(24Mbps)，- 76dBm(36Mbps)，-71dBm(54Mbps) 11n: -83dBm(MCS0)，-65dBm(MCS7)，- 83dBm(MCS8)，-65dBm(MCS15) 11ac: 20MHz: -83dBm(MCS0), -57dBm(MCS9) 11ac: 40MHz: -79dBm(MCS0), -57dBm(MCS9) 11ac: 80MHz: -76dBm(MCS0), -51dBm(MCS9) 11ax: 20MHz: -85dBm(MCS0), -58dBm(MCS11) 11ax: 40MHz: -82dBm(MCS0), -54dBm(MCS11) 11ax: 80MHz: -79dBm(MCS0), -52dBm(MCS11) |
| Dimensions |
|
| Dimensions (excluding mounting kits) |
194 mm x 194 mm x 35 mm (7.64 in. x 7.64 in. x 1.38 in.) |
| Weight |
≤ 0.55 kg (1.21 lbs.) |
| Service Ports |
|
| Number of 10/100/1000BA SE-T
Ports |
2 (1 port supports 802.3at PoE) |
| Number of 10/100/1000/25 00BASE-T
Ports |
0 |
| Number of 100/1000/2.5G/
5G/10GBASE-T Ethernet Ports |
0 |
| Number of 1 Gbps Optical Ports
(SFP) |
0 |
| Number of 10 Gbps Optical Ports
(SFP+) |
0 |
| Power Supply |
|
| DC (Local Power) |
Yes (12V/1.5A) |
| DC Port Dimensions |
Outer Diameter: 5.5 mm Inner Diameter: 2.1 mm Length: 10 mm |
| 802.3af |
No |
| 802.3at |
Yes |
| 802.3bt |
N/A |
| 48 V passive PoE |
N/A |
| PoE Out |
No |
| Power Consumption |
< 15.5W |
| Power Adapter |
No |
| Buttons |
|
| Buttons |
1 × Factory reset |
| LEDs |
|
| LEDs |
1 × System LED
indicator(green) |
| Environment |
|
| Operating Temperature |
0°C to +40°C (32°F to +104°F) |
| Storage Temperature |
–40°C to +70°C (–40°F to
+158°F) |
| Operating Humidity |
5% to 95% (non-condensing) |
| Storage Humidity |
5% to 95% (non-condensing) |
| Mounting |
|
| Ceiling-mount |
Yes |
| Wall-mount |
No |
| Pole-mount |
No |
| Compliance
Standards |
|
| Health |
EN IEC 62311:2020 |
| Spectrum |
EN 300 328 V2.2.2 EN 301 893 V2.1.1 EN 300 440 V2.2.1 |
| Weatherproof |
|
| IP Rating |
IP41 |
| Lightning Protection/Surge |
±2 kV |
| Software |
|
| Operating Mode |
Router Mode AP Mode |
| WLAN |
|
| Recommended Number of
Clients |
11ax STA: 16(2.4G)+84(5G)=100 11ac STA: 16(2.4G)+64(5G)=80 |
| Max. Number of SSIDs |
8 |
| Radio-based STA Limit |
Yes |
| Layer 2 Client Isolation |
Yes |
| OFDMA Subcarrier |
Yes |
| OFDMA |
Yes |
| Wi-Fi Multimedia (WMM) |
Yes |
| 802.1Q VLAN |
Yes |
| Multi-Link Operation (MLO) |
No |
| 4K-QAM |
No |
| Same SSID for Different
VLANs |
Yes |
| AP Load Balancing Management |
No |
| IGMP Snooping |
No |
| RF Beamforming |
Yes |
| Roaming |
|
| 802.11k/v |
Yes |
| 802.11r |
Yes |
| Layer 2 Roaming |
Yes |
| Layer 3 Roaming |
Yes |
| AI Roaming |
Yes |
| Security |
|
| PSK Authentication |
Yes |
| Static Blocklist and
Allowlist |
Yes |
| WPA (TKIP), WPA2 (AES), and
WPA-PSK |
Yes |
| OWE (Enhanced Open) WPA3-SAE WPA2-PSK/WPA3-SAE |
Yes |
| 802.1X |
Yes |
| ARP Check |
No |
| IP Source Guard |
No |
| LLDP |
No |
| Static ARP Binding |
Yes |
| Proxy ARP |
No |
| Ping |
Yes |
| Traceroute |
Yes |
| Routing |
|
| NAT |
Yes |
| Static IP Address |
Yes |
| DHCP Server |
Yes |
| PPPoE Client PPPoE Dial-up |
Yes |
| AP Mesh |
|
| Mesh Management |
Yes |
| Reyee Mesh |
Yes |
| Standalone
Portal |
|
| Captive Portal |
Yes |
| Bandwidth Limit |
Yes |
| Data Quota |
No |
| Management and
Maintenance |
|
| Default Access/Password |
Yes |
| Management and
Maintenance |
|
| No. of APs on a Self-Organizing
Network |
300 |
| Unified Networking for All Network
Equipment |
Yes |
| Local or Remote Management via Ruijie
Reyee App |
Yes |
| Local Management via the Web
Interface |
Yes |
| Remote Management via Ruijie
Cloud |
Yes |
| SNMP |
Yes |
| Platform Management
Features |
|
| Optimization of Channel, Transmit
Power, and Management Frame Power Settings. Both Pre- and Pro-
Optimization Settings are Displayed. |
Yes |
| Unified Configuration via Ruijie
Cloud |
Yes |
| Unified Monitoring via Ruijie
Cloud |
Yes |
| Others |
|
| Flash |
16MB |
| Memory |
256MB |
| Colour of AP Enclosure |
Warm White |
| Videos |
|---|
Ruijie RG-RAP62 Wi-Fi 6 AX1800 Ceiling-Mount Access Point
Reyee Mesh Solution Video
Ruijie Easy Network Solution| Files |
|---|
| Ruijie RG-RAP62 Datasheet |
| Ruijie RG-RAP62 Installation Guide |
| Ruijie RG-RAP62 User Manual |
| Links* |
|---|
| Ruijie website |
| Ruijie support site |
